Eans
Four-axle open high-wall wagon for the transport of coal, coke, ore, bulk substrate, piece goods and scrap that do not require covered space for transportation.
Empty weight: 22,5 t ± 3%
Track: 1435mm
Loading weight: 67,5 t
Weight of loaded wagon: 90 t
Axle weight: 22.5 t
Loading capacity: 72 m3
Loading area: 35.5 m2
Chassis type: Y25 Ls (s)
Maximum empty car speed: 120 km / h
Maximum speed of loaded wagon: 100 km / h
Loading length: 12.80 m
Loading width: 2.76 m
Brake: KNORR-GP-A-K
Floor height from HM: 1255 mm
Side wall height: 2025 mm
